Dhyana 400BSI V2 (BSI)

Dhyana 400BSI V2 advanced cooling mode can further reduce the impact of noise on imaging: compared to 1.2e- readout noise and 0.2e-DSNU, the dark curret corresponding to 100ms is less than 0.02e-. In high-end imaging applications,dark current becomes negligible.

To improve the overall performance of the camera, the Dhyana 400BSI V2 was calibrated in DSNU (dark signal nonuniformity) and PRNU (photo response non-uniformity) characteristically. After calibration, the DSNU value reduced from 0.3e- to 0.2e-, the PRNU value reduced from 1.6% to 0.3%. Thus the new upgraded camera has a more sophisticated capabilities, making it more suitable for quantitative analysis applications.
